PICC电磁导航——实时追踪，精准定位

参考资料：

1.Gupta N, Gandhi D, Sharma S, et al. Tunneled and routine peripherally inserted central

catheters placement in adult and pediatric population: review, technical feasibility, and troubleshooting. Quant Imaging Med Surg, 2021, 11(4): 1619-1627.

2.Gorski lA, Hadaway L, Hagle ME, et al. Infusion therapy standards of practice. J Infus Nurs, 2021, 44(suppl1): S1-S224.

3.黎丽,宋锦平,唐梦琳,等. 电磁导航定位技术在经外周静脉置入中心静脉导管尖端定位中的研究进展.中国医学装备,2023,20(4):168-173.

4.李克佳. PICC导管尖端定位方法的研究进展. 护理研究, 2020, 34(19): 3471-3474.

5.Song YG, Byun JH, Hwang SY, et al. Use of vertebral body units to locate the cavoatrial junction for optimum central venous catheter tip positioning. Br J Anaesth, 2015, 115: 252-257.

6.王晓,魏秀红,张秀霞,等. 经外周置入中心静脉导管尖端最佳位置定位的可靠影像学标志研究.重庆医学,2019,48(3):525-528.

7.Yu D, Zhang K, Huang L, et al. Detection of peripherally inserted central catheter(PICC) in chest X-ray images: A multi-task deep learning model. Comput Methods Programs Biomed, 2020, 197: 105674.

8.Pittirtti M, Scoppettuolo G, Greca A L, et al. The EKG method for positioning the tip of

PICCs: results from two preliminary studies. JAVA, 2008, 13(4): 179-186.

9.Lelkes V, KUMar A, Shukla PA, et al. Analysis of the Sherlock II tip location system for inserting peripherally inserted central venous catheters. Clin Imaging, 2013, 37(5): 917-921.

10.Campbell B, Campbell M. NICE medical technologies guidance: a novel and rigorous methodology to address a new health technology assessment challenge. Appl Health Econ Health Policy, 2012, 10(5): 295-297.

11.Johnston AJ, Holder A, Bishop SM, et al. Evaluation of the Sherlock 3CG Tip Confirmation System on peripherally inserted central catheter malposition rates. Anaesthesia, 2014, 69(12): 1322-1330.

12.Smith B, Neuharth RM, Hendrix MA, et al. Intravenous electrocardiographic guidance for placement of peripherally inserted central catheters. J Electrocardiol, 2010, 43(3): 274-278.

13.Fricke BL, Racadio JM, Duckworth T, et al. Placement of peripherally inserted central catheters without fluoroscopy in children: initial catheter tip position. Radiology, 2005, 234(3): 887-892.

14.Dale M, Morgan H, Peirce S, et al. External Assessment Centre Report: Sherlock 3CG® Tip Confirmation System for placement of peripherally inserted central catheters. [EB/OL]. (2015-06-18) [2022-11-01] 2014. http://www.nice.org.uk/guidance/mtg24/documents.

15.Yamagishi T, Ashida H, Igarashi T, et al. Clinical impact of the Sherlock 3CG® Tip Confirmation System for peripherally inserted central catheters. J Int Med Res, 2018, 46(12): 5176-5182.

16.Sainathan S,Hempstead M,Andaz S.A single institution experience of seven hundred consecutively placed peripherally inserted central venous catheters. J Vasc Access, 2014, 15(6): 498-502.

17.Bidgood C. Improving the patient experience with real-time PICC placement confirmation. Br J Nurs, 2016, 25(10): 539-543.
